Blowing EFI fuze and hot EFI relay in engine fuze box
#1
Registered User
Thread Starter
Join Date: Sep 2008
Location: B-TOWN, Oregon
Posts: 555
Likes: 0
Received 0 Likes
on
0 Posts
Blowing EFI fuze and hot EFI relay in engine fuze box
I was drivin down the road mindin my own buisness then. My truck dies. I creep over to the side of the road.
The Good-
It turns over no problem.
All the lights work.
Everything has good clean connections.
Radio works
Blows air through the vents
All fuzes in the Junction block #1 by the driver side kick panel are good.
The bad-
Blown EFI 15A fuze in engine bay fuze block (relay block #2)
Hot CMH relay (C in relay block #2) i replaced this with a new one and the new one also gets hot (when the key is left in the ON position). I also replaced the EFI relay (B in relay block #2)
The EFI fuze blows/pops the second the ignition is turned to the ON position(the position just before START when it starts crankin the motor)
When this fuze blows there is no spark i have a spark checker that goes in between the distributor and the spark plugs and there is just no spark when this fuze blows.
QUESTION
I figure there is a definate short somewhere just wondering if anyone has ever encountered something the same or similar to this. I have pulled the relay block up from the fender wall and removed the bottom to look for chaffed wires they all seem to be in good condition. My mechanic friend sais sometimes the solder on the connections by the ignition can get hot enough to melt and ground each other out. I am at a loss right now. And have gone through more fuzes than.....someone that goes through a lot of fuzes. i have tried everything from 15A up to 30A they all pop just the same the second the key is turned to the ON position.
The Good-
It turns over no problem.
All the lights work.
Everything has good clean connections.
Radio works
Blows air through the vents
All fuzes in the Junction block #1 by the driver side kick panel are good.
The bad-
Blown EFI 15A fuze in engine bay fuze block (relay block #2)
Hot CMH relay (C in relay block #2) i replaced this with a new one and the new one also gets hot (when the key is left in the ON position). I also replaced the EFI relay (B in relay block #2)
The EFI fuze blows/pops the second the ignition is turned to the ON position(the position just before START when it starts crankin the motor)
When this fuze blows there is no spark i have a spark checker that goes in between the distributor and the spark plugs and there is just no spark when this fuze blows.
QUESTION
I figure there is a definate short somewhere just wondering if anyone has ever encountered something the same or similar to this. I have pulled the relay block up from the fender wall and removed the bottom to look for chaffed wires they all seem to be in good condition. My mechanic friend sais sometimes the solder on the connections by the ignition can get hot enough to melt and ground each other out. I am at a loss right now. And have gone through more fuzes than.....someone that goes through a lot of fuzes. i have tried everything from 15A up to 30A they all pop just the same the second the key is turned to the ON position.
#2
Registered User
There's actually more then a few threads like this..
Some dealing with bad COR's..
Mine had to do with bad wiring inside the fuel tank (dont ask)
More common ones have to do with the 02 sensor wiring shorting out due to melting from heat from the transmission..
Use the advanced search feature and check in the 86-95 folder search quote "15A* EFI* fuse"
make sure to use the asterisk as it will search for 3letter words with them. Good luck.
Some dealing with bad COR's..
Mine had to do with bad wiring inside the fuel tank (dont ask)
More common ones have to do with the 02 sensor wiring shorting out due to melting from heat from the transmission..
Use the advanced search feature and check in the 86-95 folder search quote "15A* EFI* fuse"
make sure to use the asterisk as it will search for 3letter words with them. Good luck.
#4
Registered User
Thread Starter
Join Date: Sep 2008
Location: B-TOWN, Oregon
Posts: 555
Likes: 0
Received 0 Likes
on
0 Posts
There's actually more then a few threads like this..
Some dealing with bad COR's..
Mine had to do with bad wiring inside the fuel tank (dont ask)
More common ones have to do with the 02 sensor wiring shorting out due to melting from heat from the transmission..
Use the advanced search feature and check in the 86-95 folder search quote "15A* EFI* fuse"
make sure to use the asterisk as it will search for 3letter words with them. Good luck.
Some dealing with bad COR's..
Mine had to do with bad wiring inside the fuel tank (dont ask)
More common ones have to do with the 02 sensor wiring shorting out due to melting from heat from the transmission..
Use the advanced search feature and check in the 86-95 folder search quote "15A* EFI* fuse"
make sure to use the asterisk as it will search for 3letter words with them. Good luck.
#7
Registered User
Thread Starter
Join Date: Sep 2008
Location: B-TOWN, Oregon
Posts: 555
Likes: 0
Received 0 Likes
on
0 Posts
Yes there are many causes..
Oh, Theres no refrence to which engine were talking about !?
IMO it could be the COR
Look through This page, At the bottom of the next topic it says things about the Circuit Opening Relay.
It shows a diagram and how to test it..
Oh, Theres no refrence to which engine were talking about !?
IMO it could be the COR
Look through This page, At the bottom of the next topic it says things about the Circuit Opening Relay.
It shows a diagram and how to test it..
Trending Topics
#9
Registered User
Thread Starter
Join Date: Sep 2008
Location: B-TOWN, Oregon
Posts: 555
Likes: 0
Received 0 Likes
on
0 Posts
BAM problem found and solved. thanks for the hints on searchin SCUBA i got a serious problem with the o2 sensor wires so for now i just cut them wrapped them up in electrical tape and zip tied them away from anything. How will no o2 sensor affect its drivin abilities
