Digital Cluster
Apr 13, 2019 | 08:06 PM
#21
Registered User
Joined: Apr 2019
Posts: 1
Likes: 0
From: Butte County, CA
i fixed it before taking it out, it was a bad grounding issue. i realized that after i did my trans swap i only connected the battery to the body, not any other ground.
UPDATE: I have everything working except for the fuel gauge (need a new sender for the gauge). I even put LED's to light up the dash!.
UPDATE: I have everything working except for the fuel gauge (need a new sender for the gauge). I even put LED's to light up the dash!.
Apr 14, 2019 | 07:20 AM
#23
Just joined. I know I am bumping an old thread but my 87 turbo 4runner just started having the same issue. I turned on my heater and the digital cluster started flashing... but it won't stop now. I have owned the 4runner for about a 2 months and never had an issue, even with running the heat. Can you elaborate on the grounding issue that you found? I would really appreciate it. Or if anyone else has had this issue and has insight. Thanks!
Clean up the ground in the kickpanel, fiddle with the dimmer, check your battery/charge system and that all the connectors are clean and firm.
Dec 7, 2019 | 08:14 AM
#24
Registered User
Joined: May 2019
Posts: 6
Likes: 0
Somebody have this Image complete I need for one swap cluster sr5 on mi diésel truck
[QUOTE=weaselman;52066922]click all images to make bigger.
I have a digital cluster in my turbo 4 runner as of right now. i want to replace it because of this problem (see video) and i don't really like the digital cluster anyways.
VIDEO:
this is with me turning on the heater/headlights/rolling up windows
PIC:
Attachment 163515
i have this turbo cluster out of a pickup.
what is it going to take to swap out?
i have studied all the wiring diagrams and troubleshooting guides for the cluster, but i cant find a diagram like this for the digital cluster.
Attachment 163516
Somebody have this Image complete plz?
I have a digital cluster in my turbo 4 runner as of right now. i want to replace it because of this problem (see video) and i don't really like the digital cluster anyways.
VIDEO:
this is with me turning on the heater/headlights/rolling up windows
PIC:
Attachment 163515
i have this turbo cluster out of a pickup.
what is it going to take to swap out?
i have studied all the wiring diagrams and troubleshooting guides for the cluster, but i cant find a diagram like this for the digital cluster.
Attachment 163516
Somebody have this Image complete plz?
Jul 13, 2022 | 04:32 PM
#25
Registered User
Joined: Jul 2022
Posts: 1
Likes: 0
Camry Gen 2 cluster
If you decide to convert to analog:
Have you seen the Electrical Wiring Diagram manual? 1987 4runner/Pickup EWD Manual. It will have the wiring diagram for the analog and digital gauge. You will also likely need the same manual for the year that your analog came from, UNLESS someone can positively tell you that the wiring in the 87' analog is the same as whatever year your analog is from (88-89?). You may say "i'm sure it is..", but that is not the case with 2nd Gen Toyota Camry's (87'-91'), I know from my own and others experience. There are slight differences.
In the Camry world it is rare to have a digital gauge, so when someone finds one at the yard it is common to want to do the opposite of what you want to do.
Just like you've noticed with your 4runner, there are different plugs and the wiring is different. For the most part, with the two diagrams from the manuals, you can rewire to the correct plugs. I started working on mine and then had to stop...wedding took priority.
You can see that I have the 87' and 90' electrical manuals. Blue painted fuel gauge senders are the digital ones. Rheostats (dimmer switch) may need to be swapped out also, I know for the Camry it does.
Image I found of 87' EWD manual
Attachment 163512
2nd Gen Camry
Attachment 163513
Attachment 163514
Have you seen the Electrical Wiring Diagram manual? 1987 4runner/Pickup EWD Manual. It will have the wiring diagram for the analog and digital gauge. You will also likely need the same manual for the year that your analog came from, UNLESS someone can positively tell you that the wiring in the 87' analog is the same as whatever year your analog is from (88-89?). You may say "i'm sure it is..", but that is not the case with 2nd Gen Toyota Camry's (87'-91'), I know from my own and others experience. There are slight differences.
In the Camry world it is rare to have a digital gauge, so when someone finds one at the yard it is common to want to do the opposite of what you want to do.
Just like you've noticed with your 4runner, there are different plugs and the wiring is different. For the most part, with the two diagrams from the manuals, you can rewire to the correct plugs. I started working on mine and then had to stop...wedding took priority.You can see that I have the 87' and 90' electrical manuals. Blue painted fuel gauge senders are the digital ones. Rheostats (dimmer switch) may need to be swapped out also, I know for the Camry it does.
Image I found of 87' EWD manual
Attachment 163512
2nd Gen Camry
Attachment 163513
Attachment 163514
Jan 25, 2023 | 07:46 PM
#26
Registered User
Joined: Jan 2023
Posts: 1
Likes: 0
From: california
I know I'm 10 years late to the party but I was wondering if you still had the digital cluster because I have an 89 Camry wagon and I want to install a digital cluster but I haven't been able to find one anywhere so Ive been doing some detective work trying to find one any way possible.
