Lift this weekend, any pointers????
06-27-2003, 12:00 PM
#1
Contributing Member
Thread Starter
Join Date: Feb 2003
Location: Seattle, WA
Posts: 2,858
Likes: 0
Received 0 Likes
on
0 Posts
Lift this weekend, any pointers????
Okay folks, will be installing OME coils and shocks in the back, SAWS in the front. Pointers I've run across-
1) make sure the longer of the two OME coils is on the gas tank side of the vehicle, regardless of what the label says.
2) Spray penetrating oil on everything the night before to ease loosening of bolts.
3) Install SAWS valve facing inboard.
4) Measure before and after install to get an idea of lift.
Any other tips? Did you guys disconnect the rear brake lines during the install?
1) make sure the longer of the two OME coils is on the gas tank side of the vehicle, regardless of what the label says.
2) Spray penetrating oil on everything the night before to ease loosening of bolts.
3) Install SAWS valve facing inboard.
4) Measure before and after install to get an idea of lift.
Any other tips? Did you guys disconnect the rear brake lines during the install?
06-27-2003, 12:17 PM
#2
Contributing Member
Join Date: Sep 2002
Location: Urbandale, IA
Posts: 7,112
Likes: 0
Received 0 Likes
on
0 Posts
You nailed it with #1 & 2!
If you have a set of wrachet wrenches, it will make disconnecting the sway bars and the front upper shock mounts go much faster.
Definitely get some penetrant on the upper shock mounts, both front and back.
If you have a set of wrachet wrenches, it will make disconnecting the sway bars and the front upper shock mounts go much faster.
Definitely get some penetrant on the upper shock mounts, both front and back.
06-27-2003, 12:19 PM
#3
Contributing Member
(no help here, sorry)
David,
I can't help with the lift, since I can't afford the parts quite yet. Question for ya though... How much effect did the TJM have on you w/o any lift? I've got one sitting around waiting for the money for the lift, but it's taking a LOT of room in my apt!
Thanks!
I can't help with the lift, since I can't afford the parts quite yet. Question for ya though... How much effect did the TJM have on you w/o any lift? I've got one sitting around waiting for the money for the lift, but it's taking a LOT of room in my apt!
Thanks!
06-27-2003, 12:19 PM
#4
Contributing Member
Join Date: Dec 2002
Location: The Lone Star State
Posts: 2,424
Likes: 0
Received 0 Likes
on
0 Posts
I know that my truck is a 2nd gen, but this may apply to your truck too. When I installed my rear coils, it made it much easier to disconnect the sway bar. We then jacked up the opposite side of the axle that we were working on. This made it much easier to push down the drum and reinstall the coils. I didn't use a coil compressor either.
I know you mentioned presoaking everything already, but I can't stress enough that you make sure you get everything. I didn't soak the nuts on top of the shocks and we ended up spending an hour trying to get one nut off that was rusted on. And that was using an air impact wrench. I've heard that PB Blaster is good stuff for the job but have yet to use any.
Good Luck with the install.
EDIT: mertztr, you beat me to it. And you touched on almost everything I said.
I know you mentioned presoaking everything already, but I can't stress enough that you make sure you get everything. I didn't soak the nuts on top of the shocks and we ended up spending an hour trying to get one nut off that was rusted on. And that was using an air impact wrench. I've heard that PB Blaster is good stuff for the job but have yet to use any.
Good Luck with the install.
EDIT: mertztr, you beat me to it. And you touched on almost everything I said.
Last edited by AgRunner06; 06-27-2003 at 12:23 PM.
06-27-2003, 12:23 PM
#5
Contributing Member
Thread Starter
Join Date: Feb 2003
Location: Seattle, WA
Posts: 2,858
Likes: 0
Received 0 Likes
on
0 Posts
Scottiac,
I didn't measure to see how much the drop was, but if there is one, it isn't real noticeable. The vehicle will handle a bit strange until you get used to the extra weight in the front, but I'd go ahead and install it without the lift- mine already took a good hit offroading, so it has some scratches on it already. I get alot of looks while driving around.
I didn't measure to see how much the drop was, but if there is one, it isn't real noticeable. The vehicle will handle a bit strange until you get used to the extra weight in the front, but I'd go ahead and install it without the lift- mine already took a good hit offroading, so it has some scratches on it already. I get alot of looks while driving around.
06-27-2003, 12:23 PM
#6
Contributing Member
Join Date: Oct 2002
Location: Los Alamos, NM
Posts: 1,105
Likes: 0
Received 0 Likes
on
0 Posts
5) Review sschafer's site . Its pretty thorough.
6) Get a strap-wrench for taking off the rear shocks top mount. This lets you hold a wrench on the top nut and use the strap-wrench to turn the upper part of the shock, i.e. the dust cover. On the rears, the dust cover is welded to the top mount.
I didn't disconnect any brake lines.
6) Get a strap-wrench for taking off the rear shocks top mount. This lets you hold a wrench on the top nut and use the strap-wrench to turn the upper part of the shock, i.e. the dust cover. On the rears, the dust cover is welded to the top mount.
I didn't disconnect any brake lines.
